Dormakaba (Stanley) QED100 Series, Heavy Duty, Grade 1 Surface Vertical Rod Exit Device
SKU:DK QED 100 SVR
$891.89-$936.52
Reset Selections
- Chat With An Expert
- Resources & Tools
- Return Policy
- Request Volume Pricing
Product Overview
Dormakaba's QED100 Series Exit Devices are heavy duty and tested and certified to significantly exceed 1,000,000 cycles, well above the requirements for Grade 1 certification. Thru-bolt trim design for increased security and durability. Consistent styling allows for harmonization with other Staley Commercial Hardware products. Fire rated products are UL/cUL listed (3 hours) for "A" label door applications (8' x 8').
Warranty Information
Limited Lifetime
Specifications
- ADA CompliantYes
- BAA CompliantNo
- Backset2-7/8"
- BoltStainless Steel Latchbolt
- Bolt Throw Length1/2" (13mm)
- Country of OriginTaiwan
- Door Thickness1-3/4" (44.5mm)
- Door Width29" Fire Rated / 30" Panic with Dogging
- Duty Weight/ClassHeavy Duty
- FastenersWood screws, machine screws and sex bolts included
- GradeGrade 1
- HandNon-Handed
- Hardware FinishSatin Chromium Plated 626/US26D
- Length33" Device, 20-1/2" Pushpad
- MaterialBrass; Bronze; Steel
- Projection3"
- SeriesQED 100 Series, Grade 1 Heavy-Duty Exit Devices
- StandardsANSI; BHMA; UL
- Stiles3-1/2" Minimum
- StrikeIncluded
- Through BoltsYes
- TrimNot Included
- TypeSurface Vertical Rod
- Unit of MeasureEach
- Use WithQET100 Exit Device Trim
- Weight14.5
