Product Overview
The 1006 series is the strongest and most versatile electric strike available. The dual interlocking plunger design and heavy duty stainless steel construction, enables it to exceed every standard developed for electric strikes. With multiple faceplate options, the 1006 will fully accommodate every lock designed to work within an ANSI 4-7/8" strike plate. Tested to exceed 3000 lbs. of static strength, 350 ft-lbs. of dynamic strength and factory tested to exceed 1000000 cycles of operation, the 1006 is in a class of its own. Additional features: tamper resistant, plug-in connector, and full keeper shims for horizontal adjustment. UL 10C fire rated, 3-hour single door and 1-1/2 hour double door (fail secure only). SecuriCare five-year, no-fault, no questions asked warranty (addition of HES SMART Pac III extends the warranty to 10 years).
Warranty Information
5 Years Limited
Specifications
- Additional InformationEndurance 1,000,000 Cycles
- Amp Draw450 mA at 12 VDC / 250 mA at 24 VDC
- ApplicationIndoor / Outdoor
- BAA CompliantYes
- Burglar RatedYes
- Configuration/ConnectorsPlug-in Connector
- Country of OriginUSA
- Depth1-11/16" (43 mm)
- Device TypeUniversal
- Duty Weight/ClassHeavy Duty
- Dynamic Strength350 ft-lb (fail secure)
- Electrical Rating12/24 VDC Dual Voltage; Continuous Duty
- Faceplate Height4-7/8"
- Faceplate Width1-1/4"
- Fire Rated180 Min
- Frame ApplicationMetal or Wood
- GradeGrade 1
- HandNon-Handed
- Hardware FinishSatin Stainless Steel 630/US32D
- Height3-5/8" (92mm)
- Holding Force3000 lbs.
- MaterialStainless Steel
- PowerHardwired
- Rated Opening CompliantYes
- SeriesHES 1006 Series Electric Strikes
- StandardsANSI/BHMA A156.31, Grade 1UL 1034 Burglary-Resistant Listed, UL 294 listed
- Static Strength2500 lb
- Unit of MeasureEach
- Use WithCylindrical Locks, Mortise Exit and Latch Locks
- Weight2.4
