Product Overview
As one of the world's only regenerative power door operators, Norton's 5800 Series ADAEZ is certified by GreenCircle to reduce energy consumption by as much as 100 percent versus other comparable operators. This compact door operator is designed to fit in the tightest of spaces, for moderate to high traffic. The Regenerative Drive System charges an onboard battery pack and connects to any 24VDC power supply. This product has been documented to help facilities meet sustainable building certification programs, including LEED, WELL, Living Building Challenge and Net Zero Energy. UL10c 90 minute positive pressure fire rating.
Warranty Information
2 Years Limited
Specifications
- ADA CompliantYes
- Additional InformationBrushless DC motor/gearbox tested 10+ million cycles
- ApplicationCommercial applications requiring Push-and-Go, Power Close, or Electric Lock Interface features
- Arm TypeShock Absorbing Arm
- BatteryBuilt in battery backup
- CommunicationIntegral RF Receiver
- Country of OriginUSA
- CoverFull Metal
- DoorsLeft or Right Hand Doors
- Duty Weight/ClassHeavy Duty
- Electric Options24VDC plug-in transformer kit for continuous automatic use applications
- FastenersMounting hardware included for virtually any door and frame; ADA1012P Hardware Kit
- GradeGrade 1
- HandNon-Handed
- Latch TypeLatch Assist ensures dependable door latching
- Mounting LocationSurface, Push or Pull Side
- Operating Voltage24VDC
- Series5800 Series ADAEZ Low Energy Power Operator
- StandardsANSI/BHMA A156 .19, ETL tested to UL/cUL 325 standard for automatic operators
- TypeSurface
- Unit of MeasureEach
- Voltage24VDC Input Port
