Sargent 8200 Series Heavy Duty Mortise Lockset, Office/Entry (8205) Function, Lockbody Only

Sargent

Sargent 8200 Series Heavy Duty Mortise Lockset, Office/Entry (8205) Function, Lockbody Only

SKU:SAR LB-8205

$638.14
$411.60
(No Reviews yet)
Write a review
Reset Selections
Product Overview
The 8200 series mortise lock, is considered the industry benchmark for all mortise locks on the market today. It is also the strongest and most durable-far surpassing ANSI/BHMA A156.13 Series 1000 Grade 1 standards in independently verified testing-for additional resistance against vandalism and unauthorized entry. Patented design and construction. Available in 60 different functions, including electromechanical, security and monitoring. UL-cUL listed for three hour fire doors and windstorm applications. Pre-assembled components make installation fool-proof. **Additional options may be available, inquire via Chat.**

Resources

Warranty Information

10 Years Limited

Specifications
  • ActionKey outside retracts latchbolt, also locks and unlocks outside trim. Trim inside always retracts latchbolt, trim outside remains locked. Thumbturn inside locks and unlocks outside trim.
  • ADA CompliantYes
  • Additional InformationAuxiliary deadlatch
  • BAA CompliantYes
  • Backset2-3/4" (70mm)
  • BoltStainless Steel Latchbolt
  • Bolt Throw Length3/4" (19mm)
  • Country of OriginUSA
  • Depth4-3/32" Case
  • Door Thickness1-3/4"
  • Duty Weight/ClassHeavy Duty
  • Faceplate Height8" (203mm)
  • Faceplate Width1-1/4" (31mm)
  • Fire Rated180 Min
  • FunctionEntrance or Office (ANSI F04)
  • GradeGrade 1
  • HandField Reversible
  • Handle TypeLever
  • Height5-31/32' Case
  • IncludesHardware
  • Keywaynone - lockbody only
  • Lever/Knob Designnone - lockbody only
  • Lock PrepMortise
  • MaterialCase: 12 gauge heavy duty wrought steel, zinc dichromate plated, 1/8" (.125") cold-rolled steel inside front, wrought steel hubs and high carbon steel spring cartridge
  • Rated Opening CompliantYes
  • Rose/Escutcheon Designnone - lockbody only
  • SeriesSargent 8200 Series Mortise Locksets
  • StandardsANSI/BHMA A156.13 Series 1000 Operational Grade 1 and Security Grade 1
  • Stiles'4-1/2" (114 mm) Minimum
  • Strikenone - lockbody only
  • Strike StandardANSI
  • Through BoltsYes
  • Unit of MeasureEach
  • Weight6.1
  • Width24/32" Case
